Molex Lever-Activated Terminal Blocks
Molex Lever-Activated Terminal Blocks simplify wire termination, shorten assembly time, and ensure secure power connections. These easy-to-use and reliable blocks deliver long-term operation even in environments subject to extreme dust or temperature. The level-activated terminal blocks are available in various mounting options to improve design flexibility in wire-to-board power transmission applications carrying up to 72A current. These blocks feature a 35° wire exit angle, up to 600V voltage, and 24AWG to 4AWG wire size range. The level-activated terminal blocks are used in industrial automation, battery storage systems, power supplies, networking systems, motor inverters, and distributed energy resource controllers.
Features
- 35° wire exit angle
- Up to 600V voltage
- 24AWG to 4AWG wire size range
- 20A to 72A current range
- -40°C to 115°C operating temperature range
- Enable reliable installation
- Ensures secure connections
Applications
- Energy and power:
- Distributed energy resource controllers
- Power transmission and distribution systems
- Smart grid monitoring and control devices
- Power grids in industry
- Electric vehicle mobility systems
- Solar and wind inverters
- Battery storage systems
- Power supplies
- Power for the data centers:
- Monitoring devices
- Networking systems
- Controls
- Industrial automation:
- Motor inverters
- Motor control centers
Motor Inverters
Networking Systems
Solar and Wind Inverters
Related Products
Molex Terminal Blocks & Barrier Strip Solutions
Provides design flexibility, secure connections, and the ability to withstand harsh environments.
View Results ( 69 ) Page
| 零件編號 | 說明 | 額定電壓 | 额定电流 | 最大線規 | 間距 | 定位數 |
|---|---|---|---|---|---|---|
| 221391-0002 | 固定式接線端子 7.50mm Pitch Lever Activated Fixed Mount PCB Term Block 35 Entry Bus Term 2 Ckt | 600 V | 40 A | 8 AWG | 7.5 mm | 2 Position |
| 221391-0003 | 固定式接線端子 7.50mm Pitch Lever Activated Fixed Mount PCB Term Block 35 Entry Bus Term 3 Ckt | 600 V | 40 A | 8 AWG | 7.5 mm | 3 Position |
| 221391-0004 | 固定式接線端子 7.50mm Pitch Lever Activated Fixed Mount PCB Term Block 35 Entry Bus Term 4 Ckt | 600 V | 40 A | 8 AWG | 7.5 mm | 4 Position |
| 221392-0002 | 固定式接線端子 7.50mm Pitch Lever Activated Fixed Mount PCB Term Block 35 Entry LR Term 2 Ckt | 600 V | 38 A | 8 AWG | 7.5 mm | 2 Position |
| 221392-0003 | 固定式接線端子 7.50mm Pitch Lever Activated Fixed Mount PCB Term Block 35 Entry LR Term 3 Ckt | 600 V | 38 A | 8 AWG | 7.5 mm | 3 Position |
| 221392-0004 | 固定式接線端子 7.50mm Pitch Lever Activated Fixed Mount PCB Term Block 35 Entry LR Term 4 Ckt | 600 V | 38 A | 8 AWG | 7.5 mm | 4 Position |
| 224930-0002 | 固定式接線端子 10mm Pitch Lever Activated Fixed Mount PCB Term Block 35 Entry Bus Term 2 Ckt | 300 V | 72 A | 4 AWG | 10 mm | 2 Position |
| 224930-0003 | 固定式接線端子 10mm Pitch Lever Activated Fixed Mount PCB Term Block 35 Entry Bus Term 3 Ckt | 300 V | 72 A | 4 AWG | 10 mm | 3 Position |
| 224930-0004 | 固定式接線端子 10mm Pitch Lever Activated Fixed Mount PCB Term Block 35 Entry Bus Term 4 Ckt | 300 V | 72 A | 4 AWG | 10 mm | 4 Position |
| 224931-0002 | 固定式接線端子 10.00mm Pitch Lever Activated Fixed Mount PCB Term Block 35 Entry LR Term 2 Ckt | 600 V | 66 A | 4 AWG | 10 mm | 2 Position |
